Generator sets with BAUDOUIN engines

Main features

• Housing: made of galvanized steel - completely corrosion resistant. Galvanized sheet metal, hot-dip galvanized and electrostatically painted.
• Frame: industrial, welded, galvanized steel for high durability and corrosion resistance.
• Fuel tank: welded and integrated into the frame.
• Mounts: anti-vibration system for increased stability.
• Control panel: ComAp Intellite AMF (optional DEIF on request).
• Doors: 40 mm thick, providing robust insulation.
• Exhaust system: noise-reducing muffler.
• Soundproofing: properly insulated enclosure reducing noise levels to 70 dB at 7m(up to 60 dB optional).
• Coolant heater: providing preheating of the engine block.
• Drain kit: hoses for draining coolant and oil with valve.
• Fuel sensors: mechanical and electric for full control of fuel consumption.
• Fasteners: stainless steel bolts only, guaranteeing durability and corrosion resistance.

Characteristics

Housing

The casing of the unit is made of galvanized steel, electrostatically painted, which ensures total corrosion resistance and durability. Thanks to its soundproof design, it significantly reduces noise levels. The modular design allows for ease of service operations, with service doors located on all sides of the genset for easy maintenance and operation. The exhaust system with muffler has been mounted inside the housing, further reducing noise emissions. The housing is designed to optimize cooling of the engine and generator, ensuring their efficient operation. The genset's design allows it to be mounted outdoors, while offering protection from the elements and keeping noise levels low.

Control panel

The control panel, enclosed in a metal enclosure with IP54 protection, is equipped with the ComAp AMF 25 control module, which allows automatic and manual control of the genset. The system monitors the parameters of the power grid and cooperates with the ATS (Automatic Transfer Switch) switching system, ensuring smooth switching between the mains supply and the genset. With intuitive operation, advanced communication features and precise monitoring of operating parameters, the panel ensures reliable performance in emergency and primary applications.

Basic equipment

• Control and control panel with indicators and measuring devices, IP54 degree of protection.
• Starting battery charger to ensure constant maintenance of the starting battery voltage.
• DC alternator for charging the battery while the engine is running.
• Thermostatic coolant heater to facilitate starting at low temperatures.
• Heavy-duty starter battery for reliable starting.
• Emergency stop button for increased safety.
• Frame with integrated fuel tank for autonomous operation of up to 8 hours.
• Anti-vibration mounts to minimize vibration during operation.
• Sensor for measuring fuel level.
• Electrical wires protected by covers.
• Muffler on the exhaust to reduce noise levels.
• Protective pads to increase stability and durability of the structure.
• Metal hinges with high mechanical resistance.
• Service door with locks for easy and safe access to components.
• Transport system for handling by crane or forklift.
